S-BG-VSX-2.5X13 CSE FLT

$1,835.80
In-stock
This product fits [] different pump model(s)
See detailed list

Product overview

Service Application:
Glycol and/or Hi-Temp Water
Shaft Size:
2.500
Mechanical Seal:
(2) S-BG-P5001891 Floating Mount
Shaft Sleeve:
(2) 2.252x2.500x5.515 SS304 Shaft Sleeves
Gasket:
(2) Volute Gaskets, (2) Gland Gaskets
Square Ring:
(2) EPR Square Rings
Slinger:
(2) Neoprene Slingers
Sundry:
(2) Lube
Material:
Ethylene Propylene Rubber (EPR)
Country of Origin:
Made in USA - Domestic & Imported Parts
Sleeve Set Screw:
Not Included- Source Locally 1/4-20UNC

S-BG-VSX-2.5X13 CSE FLT

fits these pumps
Manufacturer
Part Number
Model Number
Series
Bell & Gossett
VHS, VCS, VSCS Standard Const
8x10x13.5A
VSX-Unitized Seal-Stnd Const
Bell & Gossett
VHS, VCS, VSCS Standard Const
8x10x13.5B
VSX-Unitized Seal-Stnd Const
Bell & Gossett
VHS, VCS, VSCS Standard Const
10x12x13.5A
VSX-Unitized Seal-Stnd Const

*with exception of U.S. Seal, all manufacturer's names, part numbers, and descriptions are used for reference purposes only. It is not implied that any part is the product of these manufacturers.ca-prop-65.png
