S-BG-VSX-2.0X10 CSE FLT

$2,051.75
In-stock
This product fits [] different pump model(s)
See detailed list

Product overview

Service Application:
Glycol and/or Hi-Temp Water
Shaft Size:
2.000
Mechanical Seal:
(2) SJE-4357 Floating Mount
Shaft Sleeve:
(2) 1.752x2.000x5.068 SS304 Shaft Sleeves
Gasket:
(2) Volute Gaskets, (2) Gland Gaskets
Square Rings:
(2) EPR Square Rings
Slinger:
(2) Neoprene Slingers
Sundry:
(2) Lube
Material:
Ethylene Propylene Rubber (EPR)
Country of Origin:
Made in USA - Domestic & Imported Parts
Sleeve Set Screw:
Not Included-Source Locally 1/4-20UNC

S-BG-VSX-2.0X10 CSE FLT

fits these pumps
Manufacturer
Part Number
Model Number
Series
Bell & Gossett
VHS, VCS, VSCS
4x6x10.5A, 4x6x10.5B
VSX-Unitized Seal-Stnd Const.
Bell & Gossett
VHS, VCS, VSCS
5x6x10.5A, 5x6x10.5B
VSX-Unitized Seal-Stnd Const.
Bell & Gossett
VHS, VCS, VSCS
6x8x10.5A, 6x8x10.5B
VSX-Unitized Seal-Stnd Const.
Bell & Gossett
VHS, VCS, VSCS
8x10x10.5A, 8x10x10.5B
VSX-Unitized Seal-Stnd Const.

*with exception of U.S. Seal, all manufacturer's names, part numbers, and descriptions are used for reference purposes only. It is not implied that any part is the product of these manufacturers.ca-prop-65.png
